XJ968-20E 20tons block handler equipent

The operate weight is 25tons

Rated load:20tons

Engine:WEICHAI or cummins

  • Item NO.:

    XJ968-20E
  • Product Details
  • Configration

Block handler arrangement XJ968-20E

Whole machine

Equipped with professional air-condition, single handle pilot control system, electronic control gearshift device to ensure  easy operation, Independent transmission oil and Hyd. Oil radiator improve the system stability.



Engine

Top-grade Diesel 178kw WEICHAI engine with intercooler system, with multinomial patents, synthesize multilevel compound desert air filter technology, high efficiency, low noise and cooling technology, especially using in dusty environment.



Oil pipe

oil-pipes for high-pressure position adopts high-value and durable PARKER pipe. More reliable and durable.



Transmission and torque converter

Adopt CAT technology fixed shaft power shift transmission system, compact structure, long service life of gear. Make the whole machine more flexible, special for the harsh quarries’ working environment.



Engine


Model                                                                   WEICHAI

Rated Power                                                       178kw


Overall dimension

Overall length                                                      8550mm

Overall width                                                        3105mm

Overall height                                                      3450mm

Performance parameters of entire machine

Operating weight                                                 28T

Max.load in Max.lifting height                              18T / 3700mm

Rated load                                                          20T / 2600mm

Turning angle                                                         35°

Turning radius                                                     7620mm

Wheel base                                                          3375mm

Tread                                                                      2415mm

Min.ground clearance                                           580mm

Haul location height                                               300mm

Climbing gradient                                                  30°

Fuel tank capacity                                                 280L

Hydraulic fuel tank capacity                                  280L

Dimensions of fork

L x W x H                                                                1500 x 220 x 130 mm

Distance of fork                                                     1350mm

Specification of tire

Front wheel                                                            26.5-25-36PR

Rear wheel                                                            26.5-25-28PR
